230 Smart Oscillating Beam lamp

230 Smart Oscillating Beam lamp


Technical Specifications

Product parameters:

Power supply: AC220V-240V 50/60Hz

Power consumption: 450W

Light source: Uses 230 platinum light source

Color temperature: 8500K

Color: With 14 colors + white light, it can achieve a half-color color effect. Color rainbow effect.

Static pattern: 1 fixed pattern wheel with 17 patterns + white light, with variable speed jitter. water flow effect.

Prism effect: A 16-inch rotating prism can be rotated in both directions.

Lens: High-precision glued optical lens. It adopts imported full coating technology.

Atomization effect: It can achieve atomization soft light effect and stage surface light effect.

Beam Angle: electric focusing, 2.5° beam Angle.

Horizontal vertical: Horizontal scanning Angle 540° (16-bit precision scanning), vertical scanning Angle 27 (16-bit precision scanning). It can automatically correct and position.

Dimming stroboscopic: Linear dimming 0~100%

Motor: Equipped with a silent motor, it not only provides fast and smooth scanning. And eliminate the transmission noise.

Control channel: 16CH channel mode.

Heat dissipation system: Built-in convection fan with overheat protection function.

Other functions: Remote control of bulb on/off function, display of lamp and bulb usage time. Protection level: IP20.

Appearance: High-temperature resistant plastic + molded alloy material.

Net weight of lamp: 14KG.

Total weight of lamp: 16KG.

Lamp size: 340*260*520MM.

Packaging size: 450×430×530mm


Lamp Effect
